Steel Trench Box Shields

We have steel trench box shields ranging from lightweight boxes for utility and general maintenance to large boxes for the deepest, toughest projects.

We have a complete inventory of steel trench box shields ranging from lightweight boxes for utility and general maintenance to large boxes in 4, 6, and 8-inch thick walls designed for the deepest, toughest projects.

The trench boxes are built with high-strength steel. Four lifting points are built into the sidewalls with pulling eyes. They are adjustable and stackable. The compressed wood in the top horizontal limits bucket damage. The bottom is horizontally protected by a steel drag plate.

CALL US. (832) 200-0988

Or contact us by email info@ntsafety.com.

Steel trench shields manufacturer and supplier

Key Benefits

NTS maintains one of the nation’s largest rental fleets of steel trench shields
All NTS steel trench shields are built to NTS’s stringent specifications to withstand the most demanding applications and maximize the strength-to-weight relationship
Rental fleet inventory typically ranges from 4’ to 10’ tall trench shields and 8’ to 32’ lengths, with specialty customized trench shields also available
Lightweight trench shields and single wall trench shields are also available, in addition to conventional double wall trench shields
Standard NTS features include four-point lifting systems, reinforced through wall collar design and heavy-duty stacking sockets

Optional Features

Fall Protection Guard Rails
Wheel Kit
Box Walkway
Pulling Tongue
Grade Plate

Get Product Guide

Request a quote

Please submit an inquiry below. One of our team members will contact you to discuss your requirements.

Interest?

First Name

Last Name

Phone Number

Project ZIP Code

Project Type

Message

This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

Technical Information

SIZE	CAPACITY	WEIGHT	A	B	C-60	C
DW40412	3,300	3,494	40	30	30	20
DW40416	1,720	4,364	40	30	30	20
DW40420	1,050	5,291	40	27	20	15
DW40424	710	6,162	32	18	13	10
DW40810	1,683	5,087	40	30	30	20
DW40812	1,400	5,850	40	30	27	20
DW40816	1,310	8,038	40	30	26	19
DW40820	1,050	9,786	40	27	20	15
DW40824	700	11,287	31	17	13	10
DW60820	1,450	11,250	40	30	29	22
DW60824	1,013	12,954	40	26	20	15
DW61020	900	12,994	40	23	17	13
DW61024	887	15,496	40	23	17	13
